موتور آتشفشانی
مشخصات محصول
| نام تجاری: | آتشفشان الکتریک | شماره مدل: | VOL-BL037C12 | تایپ کنید: | موتور DC بدون جاروبک |
| توان خروجی: | 0.37kW | ولتاژ DC: | 12V | محدوده سرعت: | 1700 دور در دقیقه |
| کنترل کننده: | سفارشی, اختیاری | Brake: | اختیاری | کلاس عایق: | کلاس B/F/H |
| محوطه: | IP44/IP54 | لهستانی ها: | 4پ, 6پ, 8پ… | سیم: | 100% مس |
| فعلی: | 58.82الف | سنسور: | سنسور هال, اختیاری | گواهینامه: | CE,UL,ROHS |
| مسکن: | قاب آلومینیومی | کارایی: | تا 80 | ||
| وظیفه: | S1 (مستمر) | محل مبدا: | ژجیانگ, چین (سرزمین اصلی) | استاندارد: | IEC/NEMA |
| برنامه: | قایق, ماشین, EV, فن, لوازم خانگی, موتور کششی, پمپ, سیستم های تهویه مطبوع اتوبوس ,دیگر | ||||
توضیحات محصول
Volcano Electric BLDC Motor – 12V 370W 1700RPM, this brushless DC motor operates at 12V with a rated power of 370W and a rated speed of 1700RPM under continuous duty. It features IP54 protection, is equipped with Hall sensors, delivers a rated torque of 2.08 N·m, and runs at approximately 80% بهره وری. The motor weighs 15 kg.
Designed for electric vehicle applications, this model is commonly used in small electric forklifts. It uses a B14 flange mounting configuration. EV motors are widely used across electric forklifts, lifting platforms, and various types of green vehicles. Most EV motors are brushless and built with a rotor, axle, and permanent magnets, powered by DC current or batteries.
The quality of the magnet plays a crucial role in determining the motor’s efficiency. Using magnets of the wrong grade or size can significantly reduce performance. در Volcano Electric, we manufacture our own magnets—a capability we’ve had since 2004. With full control over magnet production, we ensure stable, high-quality output across all of our motor products.
Our product line mainly focuses on 48V systems, with power outputs ranging from 160W to 4500W and speeds from 1000RPM to 6000RPM. The lineup continues to expand as we keep investing in new models and applications.
If you have interesting for this motor, please feel free to contact us by info@volcanomotors.com
تصاویر تفصیلی
لیست موتورهای براشلس
| نوع موتور | خروجی | ولتاژ | بارگذاری کنید | سرعت | گشتاور نامی | لهستانی ها | کارایی | سر و صدا |
| KW | V | الف | دور در دقیقه | N.m | % | دسی بل | ||
| VOL-BL037C12 | 0.37 | 12 | 39.8 | 1700 | 2.08 | 8 | 80 | 62 |
| VOL-BL090C24 | 0.9 | 24 | 44.6 | 2600 | 3.31 | 8 | 84 | 60 |
| VOL-BL100C30 | 1 | 30 | 43 | 1200 | 7.96 | 8 | 88 | 60 |
| VOL-BL120C24 | 1.2 | 24 | 63.3 | 4200 | 2.73 | 8 | 79 | 60 |
| VOL-BL120C36 | 1.2 | 36 | 39.7 | 2270 | 5.05 | 8 | 84 | 60 |
| VOL-BL125C24 | 1.25 | 24 | 62 | 3200 | 3.73 | 8 | 84 | 60 |
| VOL-BL130C36 | 1.3 | 36 | 40.12 | 3200 | 3.88 | 8 | 90 | 60 |
| VOL-BL150C24 | 1.5 | 24 | 73.5 | 2590 | 5.53 | 8 | 85 | 61 |
| VOL-BL150C310 | 1.5 | 310 | 6.2 | 3500 | 4.09 | 8 | 89 | 61 |
| VOL-BL200C24 | 2 | 24 | 98.6 | 3360 | 5.68 | 8 | 84.5 | 61.5 |
| VOL-BL360C24 | 3.6 | 24 | 193.5 | 3000 | 11.46 | 8 | 84.7 | 61.5 |
مزایای موتورهای DC بدون جاروبک
- Minimal maintenance and longer service life — no brushes or commutators to wear out
- Quiet operation — no brush contact reduces operating noise
- Higher power-to-weight ratio
- High efficiency — typically over 90%
- Lower temperature rise — improved heat dissipation due to the winding design
- Simple mechanical structure
- Reduced EMI
موتورهای سفارشی
برای موتورهای سفارشی, لطفا با تکنسین ما تماس بگیرید, معمولی, برای دریافت پروپوزال حرفه ای باید اطلاعات زیر را بدانیم:
- نوع موتور: Brushed or brushless, based on your preference
- توان خروجی: Specify horsepower/wattage/torque at rated speed
- ولتاژ: i.e. 12V DC to 220V AC
- سرعت (دور در دقیقه): Required shaft speed at rated voltage under full load
- برنامه: به عنوان مثال, traction systems, ventilation, و غیره.
- چرخه وظیفه: Most motors are rated for continuous operation, but some applications may require motors designed for intermittent use
- Frame and configuration: Our motors follow IEC standards, and we can customize shaft and flange dimensions based on your drawings
- Controller requirements: Such as forward/reverse operation, سرعت متغیر, or specific acceleration profiles, و غیره.
